BetaFPV Air Brushless Flight Controller

Description

The BetaFPV Air Brushless Flight Controller revolutionizes ultralight 1S whoop drones with a 55% increase in computing speed, lightning-fast response times, and precise control. Experience seamless integration, advanced features, and unmatched performance in a lightweight design that outpaces the competition.

Suits Air65 and Air75 Models.

Features

• Air Brushless Flight Controller, the first 1S FC that utilizes the G473 processor, experienced a remarkable 55% increase in computing speed and lightning-fast response times for precise racing and complex freestyle maneuvers, surpassing the F411.
• Higher integration yet lightweighter design, featuring a custom miniature OSD chip. Weighing only 2.9g (4IN1 Version) or 3.6g (5IN1 Version), it offers extra UART port options for effortless function expansions, adapting flawlessly to any flight scenario.
• Default integrated onboard 25-400mW VTX. Streamlines installation saves space, reduces weight, and boosts convenience for VTX and FC adjustments. The 5IN1 Version even integrates the Serial ELRS 2.4G RX.
• Elevate your drone’s precision with the industry-leading ICM42688P gyro, integrated accelerometer, cutting-edge sensor calibration, and filtering algorithms, and a sample rate of up to 8K, which takes the drone’s posture and movement accurate and precise drone to the next level.
• Unlock extensive flight data recording and analysis with an impressive up to 16MB capacity black box. Maximize performance and diagnose faults effectively, leveraging the full potential of your drone.

Specifications

• Weight: 2.9g(4IN1 Version) / 3.6g(5IN1 Version)
• Mounting Hole Size: 26mm x 26mm
• CPU*: STM32G473CEU6 (168MHz)
• Six-Axis: ICM42688P (SPI connection)
• Blackbox Memory: 16MB
• Sensor:  Voltage&Current
• 5V BEC*: 5V 3A
• USB Port: SH1.0 4-Pin
• Built-in ESC with 5A continuous
• RX: Serial ELRS 2.4G (V3.4.2) (Only 5IN1 Version)
• 4IN1 Version: FC+ESC+OSD+VTX
• 5IN1 Version: FC+ESC+OSD+VTX+RX

Package Includes:

• 1 x BetaFPV Air Brushless Flight Controller
