Description
The ToolkitRC M6AC AC/DC Charger redefines charging with 100W AC and 300W DC power, delivering up to 15A for rapid, precise performance. Featuring dual input, a 1000mA balance current with <0.005V accuracy, and an intuitive 2.0″ IPS LCD, it ensures smart functionality and comprehensive safety. More than just a charger, it offers versatile auxiliary functions, making it an essential tool for enthusiasts who demand efficiency and reliability.
Features:
- AC100W,DC300W MAX 15A ;
- DUAL INPUT, MAKE CLASSICS BETTER;
- 1000mA robust balance current&High balance accuracy <0.005V;
- Not only A charger, and many more auxiliary functions;
- Smart 2.0″ IPS LCD Display;
- Comprehensive security protection.
Specifications:
GENERAL
- Product size: 108×106×60mm
- Product weight: 350g
- Packing size: 144×158×63mm
- Packaging weight: 510g
- LCD: IPS 2.0″ LCD 320×240 px
CHARGER
- Input voltage: AC 100-240V@MAX 120W, DC 7-35V@MAX 30A
- Battery type: LiPo LiHV LiFe Lilon LTO @1-6S, NiMH @1-16S Pb@1-10S
- Balance current: 1000mA@4.2V
- Balance accuracy: <0.005V
- Charging power: 0.1-15A@300W
- Discharging power: 0.1-15A@300W Recycle Mode, 0.1-3A@15W Internal Mode
- USBA: 5.0V/1.0A @10W or upgrade
- Voltage: 1.0V-5.0V @1-6S
- Internal resistance: 0.1mΩ-99mΩ @1-6S
MEASURER
- PWM: 880us-2200us@20-400Hz
- PPM: 880us-2200us×8 CH@20-50Hz
- SBUS: 880us-2200us×16 CH@20-100Hz
OUTPUT
- PWM: 500us-2500us@20-1000Hz
- PPM: 880us-2200us×8 CH@50Hz
- SBUS: 880us-2200us×16 CH@74Hz
- Power: 0.5-15A@1-28V Mode: CC+CV
Package Includes:
- 1 x ToolkitRC M6AC AC/DC Charger
- 1 x AC Input Cable
- 1 x USB Cable
- 1 x Quick Manual
- 1 x Screen Protector
Russell (verified owner) –
Great first charger, also has some cool features like power mode to power a soldering iron etc. and can also test and centre servos with it. Great value charger
Malcolm H. (verified owner) –
Nice unit. Easy to use. Nice digital display.
German (verified owner) –
All good
