Specifications:
- Chip M10(10th Generation Chip)
- Frequency GPS L1GLONASS L1BDS B1GALILEO ESBAS L1QZSS L1
- Input Voltage 5V
- Antenna Ceramic Antenna
- Channel 72
- Battery Bilid-in
- Compass QMC5883
- Compass Orientation Plug facing direction of flight and obviously antenna up, BF: CW 180° Flip
- Baud Rate 115200bps
- Protocol Dual NMEA/UBLOX
- Output Frequency 1Hz-10Hz,10Hz default
- Speed Accuracy 0.05m/s
- Horizontal Positioning Accuracy 2D ACC1.5m(outdoor)
- Receiver Sensitivity Trace -166dBm; Capture -160dBm
- Dynamic Characteristics Height 50000m; Speed 500m/s; Acceleration 4G
- Operating Temperature -40C-+85C
- Storage temperature -40C-+105C
- Weight 2.7g
- Size 12.5*17*5mm
See the full range:
- Foxeer M10Q 120 GPS with 5883 Compass
- Foxeer M10Q 180 GPS with 5883 Compass
- Foxeer M10Q 250 GPS with 5883 Compass
