Flywoo FlyLens 85 Lite Frame kit (No LED)

The Flywoo Flylens 85 Frame Kit is a 2-inch whoop-style frame designed for indoor and narrow space flight.

$49.99

or 6 weekly interest free payments of NZD $8.33 with

Hurry! Only 2 left in stock

Ships from our Tauranga warehouse
SKU: fly11 Categories: ,

Description

The Flywoo Flylens 85 Frame Kit is a 2-inch whoop-style frame designed for indoor and narrow space flight. It’s compatible with digital and analog image transmission systems and features a protective ring and carbon black treatment. The Flylens series offers innovative solutions for micro-cinematography, enabling you to capture unique perspectives.

Features

  • FC mounting pattern is 25.5×25.5mm, the image transmission compartment mounting pattern is 20×20/25.5×25.5mm, and the motor mounting pattern is 6.6mm
  • Three-point CNC damping platform is designed to eliminate high-frequency vibration and jelly effects
  • Supports the installation of neon light strips and external GO3 and other small sports cameras
  • Quick-release structure, which only requires 4 screws to separate the upper and lower layers
  • Compatible with various mainstream devices on the market

Specifications

  • Brand: FLYWOO
  • Model: Flylens 85
  • Main Board Thickness: 2mm
  • CNC Gimbal Thickness: 1mm
  • Protective Ring Material: PC+
  • Flight Control Hole Position: 25.5×25.5mm
  • VTX Mounting: 20/25.5mm Motor Hole
  • Position: 6.6mm/Hole 1.4mm
  • Propeller Size: 2 inch
  • Weight: 25.5g (Lite)
  • Camera Hole Position (Lite): 18mm

Includes

  • 1x Flywoo FlyLens 85 Frame Kit Lite O3 – No LED

VIDEO: FLYWOO FLYLENS 85 KIT O3 UNIT Installation Guide
